Szczegóły Produktu:
|
| Zalety: | Dobra jakość i szybka dostawa | Kompatybilne: | 100% zamiennik oryginału |
|---|---|---|---|
| Dostawa: | 3-5 dni | Przemieszczenie konia:: | 1080 cm3 |
| Ilość tankowania: | 17dm3 | Cena: | More favorable price |
| Podkreślić: | Pompa hydrauliczna betonowa SPV23,Pompa hydrauliczna betonowa PV23,Pompa hydrauliczna betonowa OEM |
||
| Wielkość | Wymiar | Pompa fotowoltaiczna Sauer-DANFOSS | |||||||
| PV20 | PV21 | PV22 | PV23 | PV24 | PV25 | PV26 | PV27 | ||
| Maks. przemieszczenie | cm3 | 33,3 | 51,6 | 69,8 | 89,0 | 118,7 | 165,8 | 227,3 | 333,7 |
| Maks. przepływ | dm3min-1 | 119,5 | 159,9 | 196,1 | 230,5 | 278,9 | 348,1 | 429,59 | 557,2 |
| 4 | 6 | 4 | 1 | 4 | 8 | 8 | |||
| Pompa ładowania | cm3 | 12,3 | 12,3 | 18,03 | 18,03 | 18,8 | 32,8 | 32,8 | 65,5 |
| Maksymalne ciśnienie | MPa | 35 | |||||||
| Ciśnienie nominalne | MPa | 21 | |||||||
| Maks. ciśnienie regulacyjne | MPa | 3,5 | |||||||
| Ciśnienie ładowania | MPa | 0,8 - 2,0 | |||||||
| Maksymalne ciśnienie w przypadku | MPa | 0,25 ciągły 0,5 przerywany | |||||||
| Maksymalna prędkość + | min-1 | 3590 | 3100 | 2810 | 2590 | 2350 | 2100 | 1890 | 1670 |
| Minimalna prędkość | min-1 | 500 | |||||||
| Prędkość nominalna | min-1 | 1500 | |||||||
| Zakres kinematycznej lepkości płynu roboczego - Zaczynam. - działający - optymalny |
1000 12 - 600 25 - 35 |
||||||||
| mm2s-1 | |||||||||
| Rodzaj płynu roboczego | olej mineralny | ||||||||
| Temperatura pracy | oC | - od 40 do + 50 | |||||||
| Maksymalna temperatura płynu roboczego w zbiorniku | oC | 80 | |||||||
| Czystość płynu roboczego | μm | 10 | |||||||
| Kierunek obrotu wału | w kierunku wskazywania wskazówek zegara lub w kierunku przeciwnym | ||||||||
| Maksymalny kąt płyty swash | o | ± 18 o | |||||||
| Waga | kg | 45 | 55 | 63 | 78 | 124 | 164 | 212 | 270 |
| Rexroth | A2F12/23/28/55/80/107/160/200/225/250/335/500 |
| A2FO10/12/16/23/28/32/45/56/63/80/90/107/125/160/180/200/250/500 | |
| A7V28/55/80/107/160/225/250/355/500/1000 | |
| A6VM(A7VO)/12/28/55/80/107/160/200/250/355/500 | |
| A4VSO45/71/125/180/250/500/1000 | |
| A4V40/56/71 | |
| A4VG28/40/45/50/56/71/90/125/140/180/250 | |
| A4VTG71/90 | |
| A10VSO10/16/18/28/45/63/71/85/100/140 | |
| A10VG18/28/45/63 | |
| A11VO60/75/95/130/145/160/190/250/260 | |
| Kawasaki | K3SP36C |
| K3V63DT/112DT/140DT/180DT/280DT | |
| K3VL28/45/60/80/112/140/200 | |
| K3VG63/112/180/280 | |
| K7V63/100 | |
| K7VG180/265 | |
| K5V80/140/160/200 | |
| NV45/50/60/64/70/80/84/90/111/120/137/172/210/237/270 | |
| NX15 | |
| NVK45 | |
| KVC925/930/932 | |
| M2X55/63/96/120/128/146/150/170/210 | |
| M5X130/150/173/180/500 | |
| MX50/80/150/173/200/250/450/500/530/750 | |
| Kajaba | MAG150/170 |
| KYB87 | |
| MSG18P/27P/44P/50P | |
| Seria MSF | |
| Komatsuu | HPV 35/55/90/160 ((PC60/120/200/220/300-3/5) PC400/PC650 |
| Libherr | LPVD 35/45/64/75/90/100/125/140/165/225/250 |
| FMV075/100 | |
| LMF ((V) 45/64/75/90/100/125/140 | |
| Toshiba | PVB80/92 |
| PVC80/90 | |
| RO 015/02/025/04/08/12/15/17/20/25 | |
| Linder | HPV55/75/105/135/165/210/280 |
| HPR75/90/100/130/160 | |
| MPR28/45/63/71 | |
| HMR75/105/135/165 | |
| HMF28/35/50/ | |
| BPV35/50/70/100/200 | |
| B2PV35/50/75/105/140/186 | |
| BMF35/55/75/105/140/186/260 | |
| BMV35/55/75/105/135 | |
| BPR55/75/105/140/186/260 | |
| Sauer | PV90R(L) ((M) 030/42/55/75/100/130/180/250 |
| PV42-28/41/51 | |
| SPV15/18 | |
| KRR(LRR) 025C/030D/038C/045D | |
| MR(MS) 070/089/227/334 | |
| Eaton | 3321/3331 |
| 4621/4631 | |
| 5421/5431 | |
| 78461/78462 | |
| Vicker | PVE12/21/45 |
| TA19/MFE19 | |
| PVM 018/020/045/050/057/063/074/081/098/106/131/141 | |
| PVH 57/74/98/131/141 | |
| PVB 5/6/10/15/20/29/45/90 | |
| Yuken | A10/16/22/37/40/45/56/70/90/100/125/145/220 |
| A3H16/37/56/71/100/145/180 | |
| Parker. | PVP16/23/33/41/48/60/76/100/140 |
| PV 016/020/023/028/032/040/046/063/080/092/140/180/270 | |
| P2/3-060/075/105/145 | |
| PAVC 33/38/65/100 | |
| Hitachi | HPV050/102/105/118/135 |
| HMGC16/32/48 | |
| HMGF35/36/38/57 | |
| Tokiwa | MKV23/33 |
| Uchida | A10VD17/23/28/40/43/71 |
| AP2D12/14/18/21/25/28/36/38/42 | |
| A8VO55/59/80/86/107/115/172 | |
| Nachi | YC35-6 |
| PVD-2B-32/34/36/38/40/42/45/50 | |
| PVD-3B-54/56/60/66 | |
| PZ-6B-180/220 | |
| PVK-2B-50/505 | |
| PZ-4B-100 | |
| PVD-00B-14/16P | |
| PVD-1B-23/28/32/34 | |
| Hawe | V30D95/140/250 |
| V60 | |
| Włochy Sam | HCV50/70/90/100/125 |
| H1V55/75/108/160/226 | |
| H2V55/75/108/160/226 | |
| H1C55/75/108/1 |
